ND-70348 (E) CHAPTER 4
Page 797
Revision 3.0
AGCL
3. Data Entry Instructions
TEC
RSC
ANNEX
G
NOTE
STN
SFC
TENANT
NUMBER
(TN)
STATION
NUMBER
(STN)
Max. 6 digits
TELEPHONE
EQUIPMENT
CLASS
(TEC)
1-31
ROUTE
RESTRICTION
CLASS
(RSC)
0-15
SERVICE
FEATURE
CLASS
(SFC)
0-15
ROOM
CLASS
0-15
ANNEX
(ANX)
0-3
GROUND/
UNDERGROUND
(G)
0/1
FLOOR
(FLR)
1-127
1
12 1 1
Enter the RSC defined by the ARSC/ASCR/ADNR command. Since RSC = 0 is
preserved for ATTCON, a station can be used the RSC range from 1 to 15.
0 : Main Building
1 : Annex 1
2 : Annex 2
3 : Annex 3
0 : Ground
1 : Underground
Enter the station number with regard to the followings;
•
The number of station number (STN) digits is designated
by the ASYD command, SYS1, INDEX 16.
Enter the SFC defined by the ASFC command. Since SFC = 0 is
preserved for ATTCON, a station can be used the SFC range from 1 to 15.
When you have changed the station class, update
the data sheet for the AAST command.
ROOM CLASS
1-4 : Not Used 5 : DP (10pps)
6 : PB 7 : DP/PB
8 : DP (20pps) 9 : Not Used
10 : House Phone 11 : Not Used
12 : D
term
13 : Data Terminal
14-31 : Not Used
0-15
Note: When the D
term
is used for Guest station,
ROOM CLASS is fixed to 15 .
To Next Page
