Services Overview
104
FD 100/320Gbps NT and FX NT IHub Services Guide
3HH-11985-AAAA-TQZZA Issue: 13
LowestDefectPri : macRemErrXcon HighestDefect : none
Defect Flags : None
Mac Address : 00:07:72:ac:0d:a5 ControlMep : True
CcmLtmPriority : 7
CcmTx : 0 CcmSequenceErr : 0
Fault Propagation : disabled
LbRxReply : 0 LbRxBadOrder : 0
LbRxBadMsdu : 0 LbTxReply : 0
LbNextSequence : 1 LtNextSequence : 1
LtRxUnexplained : 0
========================================================
3.17.7 Tools Command
3.17.7.1 eth-ring
Table 50 eth-ring command
Sample output:
# tools dump eth-ring 20
ringId 20 (Up/Dn): numPaths 2 nodeId 00:07:72:ac:0d:a0
path-a, port nt-a:xfp:4 (Down), tag 40.0(Dn) status (Dn/Dn/Blk)
cc: Dn/Up 1/0, time 497 02:18:11.480, fwdStateChg: 1
path-b, port lag-30 (Up), tag 40.0(Dn) status (Up/Dn/Blk)
cc: Dn/Up 4/3, time 003 18:27:25.470, fwdStateChg: 3
FsmState= PROT, Rpl = None, revert = 300 s, guard = 5 ds
Defects =
Running Timers = PduReTx
lastTxPdu = 0xb020 Sf
path-a Normal, RxId(I)= , rx= 0x0000 Nr, cmd= None
path-b Normal, RxId(I)= 00:07:72:a8:54:a8, rx= 0x0000 Nr, cmd= None
DebugInfo: aPathSts 0, bPathSts 2, pm - assert 0 clear 0
RxRaps: ok 1 nok 0 self 0, TmrExp - wtr 0(0), grd 0, wtb 0
Flush: cnt 2 start 003 18:27:25.470 end 003 18:27:25.470 Out 0 Ack 1
Now: 003 19:00:46.200 , softReset: No - noTx 0
Seq Event RxInfo(Path: NodeId-Bytes)
Item Description
Syntax eth-ring ring-index [clear]
Context tools>dump
Description Displays Ethernet ring information in detail
Parameters ring-index — Ethernet ring index.
Values: 1 — 64
clear — Clear stats after reading
