Table 624 Show Router Aggregate Output
7.10.12.17 arp
Table 625 arp command
Table 626 describes the command output fields.
Table 626 Show ARP Table Output
Label Description
Prefix Displays the destination address of the aggregate route in dotted decimal notation.
Summary Specifies whether the aggregate or more specific components are advertised.
AS Set Displays an aggregate where the path advertised for the route consists of all
elements contained in all paths that are being summarized.
Aggr AS Displays the aggregator path attribute to the aggregate route.
Aggr IP-Address The IP address of the aggregated route.
State The operational state of the aggregated route.
No. of Aggregates The total number of aggregated routes.
Item Description
Syntax arp [ip-address | ip-int-name | mac ieee-mac-addr] summary
Context show>router
Description This command displays the router ARP table sorted by IP address.
If no command line options are specified, all ARP entries are displayed.
Parameters ip-addr — Only displays ARP entries associated with the specified IP address.
ip-int-name — Only displays ARP entries associated with the specified IP interface name.
summary - Displays an abbreviate list of ARP entries.
Label Description
IP Address The IP address of the ARP entry.
MAC Address The MAC address of the ARP entry.
Expiry The age of the ARP entry.
Type Dyn — The ARP entry is a dynamic ARP entry.
Inv — The ARP entry is an inactive static ARP entry (invalid).
Oth — The ARP entry is a local or system ARP entry.
Sta — The ARP entry is an active static ARP entry.
(1 of 2)
