Virtual Private Routed Network Service
596
FD 100/320Gbps NT and FX NT IHub Services Guide
3HH-11985-AAAA-TQZZA Issue: 13
7.10.12.35 peer
Table 660 peer command
Table 661 describes the command output fields for a RIP peer.
Table 661 Show RIP Peer Output
Metric In The metric value added to routes received from a RIP neighbor.
Metric Out The value added to routes exported into RIP and advertised to RIP neighbors.
Split Horizon Disabled — Split horizon disabled for the neighbor.
Enabled — Split horizon and poison reverse enabled for the neighbor.
Check Zero Disabled — Checking of the mandatory zero fields in the RIPv1 and RIPv2
specifications are not checked allowing receipt of RIP messages even if
mandatory zero fields are non-zero for the neighbor.
Enabled — checking of the mandatory zero fields in the RIPv1 and RIPv2
specifications and rejecting non-compliant RIP messages is enabled for the
neighbor.
Message Size The maximum number of routes per RIP update message.
Preference The preference of RIP routes from the neighbor.
Auth. Type Specifies the authentication type.
Update Timer The current setting of the RIP update timer value expressed in seconds.
Timeout Timer The current RIP timeout timer value expressed in seconds.
Export Policies The export route policy that is used to determine routes advertised to all peers.
Import Policies The import route policy that is used to determine which routes are accepted from
RIP neighbors.
Label Description
(2 of 2)
Item Description
Syntax peer [interface-name]
Context show>router>rip
Description Displays RIP peer information.
Label Description
Peer IP Addr The IP address of the peer router.
Interface Name The peer interface name.
Version The version of RIP running on the peer.
(1 of 2)
