FD 100/320Gbps NT and FX NT IHub Services Guide Virtual Private Routed Network Service
Issue: 13 3HH-11985-AAAA-TQZZA 597
7.10.12.36 statistics
Table 662 statistics command
Table 663 describes the command output fields for RIP statistics.
Table 663 Show RIP Statistics Output
Last Update The number of days since the last update.
No. of Peers The number of RIP peers.
Label Description
(2 of 2)
Item Description
Syntax statistics [ip-addr | ip-int-name]
Context show>router>rip
Description Display Interface level statistics for the RIP protocol.
If no IP address or interface name is specified, then all configured RIP interfaces are displayed.
If an IP address or interface name is specified, then only data regarding the specified RIP
interface is displayed.
Parameters ip-addr | ip-int-name — Displays statistics for the specified IP interface.
Label Description
Learned Routes The number of RIP-learned routes were exported to RIP neighbors.
Timed Out Routes The number of routes that have been timed out.
Current Memory The amount of memory used by this RIP router instance.
Maximum Memory The amount of memory allocated for this RIP router instance.
Interface Displays the name of each interface configured in RIP and associated RIP
statistics.
Primary IP The interface IP address.
Update Timer The current setting of the RIP update timer value expressed in seconds.
Timeout Timer The current RIP timeout timer value expressed in seconds.
Flush Timer The number of seconds after a route has been declared invalid that it is flushed
from the route database.
Updates Sent Total — The total number of RIP updates that were sent.
Last 5 Min — The number of RIP updates that were sent in the last 5 minutes.
Last 1 Min — The number of RIP updates that were sent in the last 1 minute.
(1 of 3)
