FD 100/320Gbps NT and FX NT IHub Services Guide Virtual Private LAN Service
Issue: 13 3HH-11985-AAAA-TQZZA 259
5.16.2.15 address
Table 138 address command
Table 139 States
Item Description
Syntax address ip-address[/mask]
no address
Context configure>service>vpls>interface
Description This command assigns an IP address, IP subnet, to a VPLS management router interface.
Only one IP address can be associated with an IP interface. An IP address and a mask are
used together to create a local IP prefix. The defined IP prefix must be unique within the context
of the routing instance. It cannot overlap with other existing IP prefixes defined as local subnets
on other IP interfaces in the same routing context within the ISAM.
The IP address for the interface can be entered in CIDR (Classless Inter-Domain Routing)
notation.
By default, no IP address or subnet association exists on an IP interface until it is explicitly
created.
Use the no form of this command to remove the IP address assignment from the IP interface.
When the no address command is entered, the interface becomes operationally down.
The operational state is a read-only variable and the only controlling variables are the address
and admin states (see Table 139). The address and admin states are independent and can be
set independently. If an interface is in an administratively up state and an address is assigned,
it becomes operationally up and the protocol interfaces and the MPLS LSPs associated with
that IP interface will be reinitialized.
Parameter ip-address — The IP address of the IP interface. The ip-address portion of the address
command specifies the IP host address that will be used by the IP interface within the subnet.
This address must be unique within the subnet and specified in dotted decimal notation.
Address Admin State Oper State
No address up down
No address down down
1.1.1.1 up up
1.1.1.1 down down
