Table 255 describes the command output fields.
Table 255 Show Service SAP Command Output Fields
Parameters sap sap-id — Specifies the physical port identifier portion of the SAP definition.
Values: {port-id | lag-id}:{vlanid | no-tag}
• port-id
Specifies the physical port ID in the following format:
<port-id>: <nwport-id | ltport-id>
nwport-id - <slot-address>:<port-type>:<port-num>
— slot-address - nt|nt-a|nt-b|ntio-1
— port-type - sfp | xfp |vp | eth | ieee1588 | AI
— port-num - port-number
ltport-id - lt:<rack>/<shelf>/<slot>
— lt - keyword
— rack - number identifying the rack
— shelf - number identifying the shelf
— slot - number identifying the slot
• lag-id
lag: keyword
id: 1 — 64
• vlanid
Specifies the VLAN ID to be associated with the port identified by the SAP. For v-VPLS,
the SAP VLAN ID must match the VLAN ID defined at the v-VPLS level. The null value can
also be specified, to indicate that the SAP will send and receive untagged frames. If this
SAP is not defined, untagged frames will be dropped.
The m-VPLS VLAN ID is always specified as no-tag, which is reserved for untagged L2CP
frames processed to be by the m-VPLS.
Values:
m-VPLS vlanid: no-tag
v-VPLS vlanid: 0 | 1— 4093 (0 specifies untagged frames)
interface — Specifies matching SAPs with the specified IP interface.
ip-address — The IP address of the interface for which to display matching SAPs.
Values: 1.0.0.0 — 223.255.255.255
ip-int-name — The IP interface name for which to display matching SAPs.
Label Description
Port ID The ID of the access or hybrid port where the SAP is defined.
Svc ID The service identifier.
I.MAC/IP The MAC or IP filter policy ID applied to the ingress SAP.
E.Mac/IP The MAC or IP filter policy ID applied to the egress SAP.
Adm The desired state of the SAP.
Opr The actual state of the SAP.
Item Description
(2 of 2)
