Virtual Private LAN Service
240
FD 100/320Gbps NT and FX NT IHub Services Guide
3HH-11985-AAAA-TQZZA Issue: 13
5.13.2 Pseudowire Template
The pw-template is defined under the top level service command
(config>service#pw-template) and specifies whether to use an automatically
generated SDP or manually configured SDP. it also provides the set of parameters
required for establishing the pseudowire (SDP binding) as displayed in Table 119.
Table 119 PW-Template CLI Tree
Legend U — Label In Use, N — Label Not In Use, W — Label Withdrawn
S — Status Signaled Up, D — Status Signaled Down
E — Epipe Service, V — VPLS Service, M — Mirror Service
A — Apipe Service, F — Fpipe Service, I — IES Service, R — VPRN Service
P — Ipipe Service, C — Cpipe Service
TLV — (Type, Length : Value)
LDP Service FEC 128 Bindings
Type VCId SvcId SDPId Peer IngLbl EgrLbl LMTU RMTU
No Matching Entries Found
LDP Service FEC 129 Bindings
AGI
Type SvcId SDPId
SAII
Peer IngLbl
TAII
EgrLbl LMTU RMTU
65535:100 1.1.1.6 1.1.1.134
V-Eth 100 17406 1.1.1.134 131063U 131067S 1464 1464
No. of FEC 129s: 1
(2 of 2)
PERs6>configure>service# pw-template 1 create
— [no] pw-template <policy-id> [create]
<policy-id> : [1..2147483647]
<create> : keyword — may be entered while creating an entry
[no] controlword - Enable/disable the use of ControlWord
[no] disable-aging - Enable/disable aging of the MAC addresses
[no] disable-learni* - Enable/disable learning of new MAC addresses
[no] force-vlan-vc-* - Forces vlan-vc-type forwarding in the data-path
igmp-snooping + Configure IGMP snooping parameters
[no] split-horizon + Configure a split horizon group
vc-type - Configure VC type
[no] vlan-vc-tag - Configure VLAN VC tag
