FD 100/320Gbps NT and FX NT IHub Services Guide Virtual Private LAN Service
Issue: 13 3HH-11985-AAAA-TQZZA 265
5.16.2.22 egress
Table 146 egress command
5.16.2.23 ingress
Table 147 ingress command
Description This command enables the use of the hash label on a VLL, or VPLS service bound to LDP
SDP.
When this feature is enabled, the ingress LER is modified so that the result of the hash on the
ingress packet header is communicated to the egress data path for use as index to select the
value of the label field of the hash label. The egress data path has a set of 128 different label
field values in the range 524.288 - 1.048.575. The egress data path appends the hash label at
the bottom of the stack (BoS) and sets the S-bit to 1 to indicate that.
The hash label, also referred to as entropy label, allows LSR nodes in a network to load
balance labeled packets in a more granular fashion than allowed by simply hashing on the
standard label stack. It also removes the need to have an LSR inspect the payload below the
label stack to check for an IPv4 or IPv6 header.
Since the ingress LER hashing routine maintains packet ordering within a conversation, this
guarantees that when an LSR sprays the packets over multiple LDP ECMP paths or multiple
paths over a LAG network port by hashing the extended label stack including the hash label,
the LSR will also maintain packet ordering within a conversation.Packets that are generated in
CPM and forwarded labeled within the context of a service (for example, OAM packets) must
also include a hash label at the BoS and set the S-bit accordingly.
The TTL of the hash label is set to a value of 1.
The no form of this command disables the use of the hash label.
Default no hash-label
Item Description
(2 of 2)
Item Description
Syntax egress
Context configure>service>vpls>mesh-sdp
configure>service>vpls>spoke-sdp
Description This command configures the egress SDP context.
Item Description
Syntax ingress
Context configure>service>vpls>mesh-sdp
configure>service>vpls>spoke-sdp
(1 of 2)
