FD 100/320Gbps NT and FX NT IHub Services Guide
3HH-11985-AAAA-TQZZA Issue: 13
Table 371 Port and Encapsulation Type Values
Parameters sap sap-id — Specifies the physical port identifier portion of the SAP definition.
Values: {port-id | lag-id}:{vlanid | no-tag}
• port-id
Specifies the physical port ID in the following format:
<port-id> : <nwport-id | ltport-id>
nwport-id - <slot-address>:<port-type>:<port-num>
— slot-address - nt|nt-a|nt-b|ntio-1
— port-type - sfp | xfp |vp | eth | ieee1588 | AI
— port-num - port-number
ltport-id - lt:<rack>/<shelf>/<slot>
— lt - keyword
— rack - number identifying the rack
— shelf - number identifying the shelf
— slot - number identifying the slot
• lag-id
lag: keyword
id: 1 — 64
• vlanid
Specifies the VLAN ID to be associated with the port identified by the SAP. For v-VPLS,
the SAP VLAN ID must match the VLAN ID defined at the v-VPLS level. The null value can
also be specified, to indicate that the SAP will send and receive untagged frames. If this
SAP is not defined, untagged frames will be dropped.
The m-VPLS VLAN ID is always specified as no-tag, which is reserved for untagged L2CP
frames processed to be by the m-VPLS.
Values:
m-VPLS vlanid: no-tag
v-VPLS vlanid: 0 | 1— 4093 (0 specifies untagged frames)
The values depends on the encapsulation type configured for the interface. Table 371
describes the allowed values for the port and encapsulation types
Port Type Encap Type Allowed Values Comments
Ethernet Null 0 The SAP is identified by the port.
Ethernet Dot1q 0 - 4094 The SAP is identified by the 802.1Q tag on the port.
Note that a 0 qtag1 value also accepts untagged
packets on the dot1q port.
Item Description
(2 of 2)
