Remote control commands
R&S
®
RTM3000
439User Manual 1335.9090.02 ─ 09
CHANnel<m>:SKEW <Skew>
Sets a delay for the selected channel.
Deskew compensates delay differences between channels caused by the different
length of cables, probes, and other sources. Correct deskew values are important for
accurate triggering.
Suffix:
<m>
.
1..4
Selects the input channel. The number of channels depends on
the instrument.
Parameters:
<Skew> Deskew value
Default unit: s
CHANnel<m>:ZOFFset[:VALue]
<ZeroOffset>
Sets the zero offset.
Differences in DUT and oscilloscope ground levels may cause larger zero errors affect-
ing the waveform. If the DUT is ground-referenced, the "Zero Offset" corrects the zero
error and sets the probe to the zero level.
You can assess the zero error by measuring the mean value of a signal that should
return zero.
Suffix:
<m>
.
1..4
Selects the input channel. The number of channels depends on
the instrument.
Parameters:
<ZeroOffset> *RST: 0
Default unit: V
CHANnel<m>:WCOLor <WaveformColor>
Selects the color scale for the waveform color. Each scale comprises a set of colors,
where each color represents a certain frequency of occurrence.
Suffix:
<m>
.
1..4
Selects the input channel. The number of channels depends on
the instrument.
Parameters:
<WaveformColor> TEMPerature | RAINbow | FIRE | DEFault
TEMPerature
Temperature colors. Blue corresponds to rare occurrences of the
samples, while white indicates frequent ones.
Waveform setup
