Remote control commands
R&S
®
RTM3000
485User Manual 1335.9090.02 ─ 09
REFCurve<m>:STATe
Displays or hides the selected reference waveform.
Suffix:
<m>
.
1..4
Selects the reference waveform.
Parameters:
<State> ON | OFF
*RST: OFF
REFCurve<m>:UPDate
Updates the selected reference by the waveform defined with REFCurve<m>:SOURce.
Suffix:
<m>
.
1..4
Selects the reference waveform.
Usage: Event
REFCurve<m>:SAVE <Filename>
Stores the reference waveform in the specified file.
Suffix:
<m>
.
1..4
Selects the reference waveform.
Setting parameters:
<Filename> String with path and file name
Usage: Setting only
REFCurve<m>:LOAD <Filename>
Loads the waveform data from the indicated reference file to the reference waveform.
To load the correspondent instrument settings, use REFCurve<m>:LOAD:STATe
on page 486.
Suffix:
<m>
.
1..4
Selects the reference waveform.
Setting parameters:
<Filename> String with path and file name
Usage: Setting only
Waveform analysis
