Remote control commands
R&S
®
RTM3000
537User Manual 1335.9090.02 ─ 09
MASK:CHCopy
Creates a mask from the envelope waveform of the source set with MASK:SOURce.
Example:
MASK:STATe ON
MASK:SOURce CH1
MASK:CHCopy
Usage: Event
MASK:YPOSition <Yposition>
Moves the mask vertically within the display.
Parameters:
<Yposition> Mask offset from the vertical center
Default unit: div
MASK:YSCale
<Yscale>
Changes the vertical scaling to stretch or compress the mask in y-direction.
Parameters:
<Yscale> A value over 100% stretches the amplitudes; a value less than
100% compresses the amplitudes.
Default unit: %
MASK:XWIDth <Xaddition>
Changes the width of the mask in horizontal direction.
Parameters:
<Xaddition> The value is added to the positive x-values and subtracted from
the negative x-values of the mask limits in relation to the mask
center.
Default unit: div
MASK:YWIDth <Yaddition>
Changes the width of the mask in vertical direction.
Parameters:
<Yaddition> The value is added to the y-values of the upper mask limit and
subtracted from the y-values of the lower mask limit.
Default unit: div
MASK:SAVE <Filename>
Saves the current mask in the specified file.
