Remote control commands
R&S
®
RTM3000
538User Manual 1335.9090.02 ─ 09
Setting parameters:
<Filename> String parameter
Path and file name
Usage: Setting only
MASK:LOAD <Filename>
Loads a stored mask from the specified file.
Setting parameters:
<Filename> String parameter
Path and file name
Usage: Setting only
17.8.2.2 Actions on violation
MASK:ACTion:SOUNd:EVENt:MODE.............................................................................. 538
MASK:ACTion:SCRSave:EVENt:MODE........................................................................... 538
MASK:ACTion:WFMSave:EVENt:MODE.......................................................................... 538
MASK:ACTion:PULSe:EVENt:MODE............................................................................... 538
MASK:ACTion:STOP:EVENt:MODE.................................................................................539
MASK:ACTion:STOP:EVENt:COUNt................................................................................539
MASK:ACTion:SCRSave:DESTination............................................................................. 539
MASK:ACTion:WFMSave:DESTination.............................................................................540
MASK:ACTion:YOUT:ENABle..........................................................................................540
MASK:ACTion:SOUNd:EVENt:MODE <EventMode>
MASK:ACTion:SCRSave:EVENt:MODE <EventMode>
MASK:ACTion:WFMSave:EVENt:MODE <EventMode>
MASK:ACTion:PULSe:EVENt:MODE <EventMode>
Defines when and how often the action is executed.
●
SOUNd: Generates a beep sound on mask violation.
●
PULSe: Creates a pulse on the [Aux Out] connector. This selection sets the config-
uration of the [Aux Out] connector to "Mask Violation".
●
SCRSave: Saves a screenshot on mask violation. To set path and filename of the
screenshot, use MASK:ACTion:SCRSave:DESTination.
●
WFMSave: Saves the waveform data on mask violation. To set path and filename
of the data file, use MASK:ACTion:WFMSave:DESTination.
Parameters:
<EventMode> OFF | EACH
OFF
No action is executed.
EACH
The selected action is executed on each violation of the mask.
