Remote control commands
R&S
®
RTM3000
564User Manual 1335.9090.02 ─ 09
BPLot:MEASurement:POINt[:DISPLAY]
Enables the display of the measurement points in the bode plot.
Parameters:
<PointDisplay> ON | OFF
BPLot:OUTPut[:SOURce]
Selects the channel for the output signal of the DUT.
Parameters:
<OutputSource> CH1 | CH2 | CH3 | CH4
*RST: CH2
BPLot:POINts:LOGarithmic
Sets the number of points per decade that are measured.
Parameters:
<PointsPerDecade> Range: 10 to 500
Increment: 1
*RST: 10
BPLot:REPeat
Repeats the measurement, using the same parameters.
Parameters:
<RepeatedMeasurement>ON | OFF
*RST: OFF
BPLot:RESet
Deletes all test results.
Usage:
Event
BPLot:STATe
Starts the Bode plot measurement.
Parameters:
<PlotState> RUN | STOP
*RST: STOP
