Remote control commands
R&S
®
RTM3000
566User Manual 1335.9090.02 ─ 09
BPLot:PHASe:DATA?
Returns the data of the phase waveform.
Parameters:
<PhaseData>
Usage: Query only
BPLot:PHASe:ENABle?
Enables the phase waveform for the Bode plot.
Parameters:
<Enable> ON | OFF
*RST: ON
Usage: Query only
BPLot:PHASe:POSition?
Sets the vertical position of the phase waveform in divisions.
Parameters:
<WaveformPosition> Range: -20.0 to 20.0
Increment: 0.1
*RST: 0.0
Usage: Query only
BPLot:PHASe:SCALe?
Sets the vertical scale for the phase waveform.
Parameters:
<WaveformScale> Range: 0.1 to 45.0
Increment: 0.1
*RST: 45.0
Usage: Query only
BPLot:AMPLitude:ENABle
Enables the amplitude waveform for the Bode plot.
Parameters:
<Enable> ON | OFF
*RST: OFF
BPLot:AMPLitude:POSition
Sets the vertical position of the amplitude waveform in divisions.
