Remote control commands
R&S
®
RTM3000
571User Manual 1335.9090.02 ─ 09
Example: Set the ASCII data format:
FORM ASC
Example: Query for data format:
FORM?
-> ASC,0
Example: Set the unsigned integer format, 16 bit data length:
FORM UINT,16
FORMat:BORDer <ByteOrder>
Defines the byte order for binary data export if FORMat[:DATA] is set to REAL or
UINT,16|32.
Parameters:
<ByteOrder> MSBFirst | LSBFirst
MSBFirst
Big endian, most significant byte first
LSBFirst
Little endian, least significant byte first
*RST: MSBF
Example: Reading waveform data in real format
ByteOrder 8 bit 16 bit 32 bit
MSBF 0xab 0xAB CD 0xAB CD 00 00
LSBF not relevant 0xCD AB 0x00 00 CD AB
17.9.1.2 Analog channels
CHANnel<m>:DATA?..................................................................................................... 571
CHANnel<m>:DATA:HEADer?.........................................................................................572
CHANnel<m>:DATA:POINts............................................................................................572
CHANnel<m>:DATA:ENVelope?...................................................................................... 573
CHANnel<m>:DATA:ENVelope:HEADer?......................................................................... 574
CHANnel<m>:DATA?
Returns the data of the analog channel waveform for transmission from the instrument
to the controlling computer. The waveforms data can be used in MATLAB, for example.
To set the export format, use FORMat[:DATA] on page 569.
To set the range of samples to be returned, use CHANnel<m>:DATA:POINts.
For envelope waveforms, use the CHANnel<m>:DATA:ENVelope? command.
