Remote control commands
R&S
®
RTM3000
646User Manual 1335.9090.02 ─ 09
BUS<b>:CAN:FRAMe<n>:STOP?
Returns the end time of the specified frame.
Suffix:
<b>
.
1..4
<n> *
Selects the frame (1...n).
Return values:
<StopTime> Default unit: s
Usage: Query only
BUS<b>:CAN:FRAMe<n>:DATA?
Returns the data words of the specified frame.
Suffix:
<b>
.
1..4
<n> *
Selects the frame (1...n).
Return values:
<FrameData> Comma-separated list of decimal values of the data bytes.
Usage: Query only
BUS<b>:CAN:FRAMe<n>:ACKState?
Returns the state of the acknowledge field.
Suffix:
<b>
.
1..4
<n> *
Selects the frame (1...n).
Return values:
<AcknowledgeState> OK | UNDF
UNDF: Undefined
Usage: Query only
BUS<b>:CAN:FRAMe<n>:ACKValue?
Returns the value of the acknowledge field.
Suffix:
<b>
.
1..4
<n> *
Selects the frame (1...n).
Serial bus analysis
