POWer:MODulation:THReshold[:UPPer] <ThresholdLevel>
Sets the threshold for unipolar sources, or the upper level for bipolar sources. The sig-
nal is measured at the crossing points of the signal with the threshold.
Parameters:
<ThresholdLevel> Default unit: V
POWer:MODulation:THReshold:LOWer <ThresholdLevel>
Sets the lower level for bipolar sources, which determines the crossing points on nega-
tive pulses.
Parameters:
<ThresholdLevel> Default unit: V
POWer:MODulation:THReshold:HYSTeresis
<Hysteresis>
Sets the hysteresis for correct edge detection.
Parameters:
<Hysteresis> Default unit: V
POWer:MODulation:EXECute
Starts the modulation analysis measurement.
Usage:
Event
POWer:MODulation:REPort:ADD
Adds the result to the report list.
Usage:
Event
POWer:MODulation:RESult:LPEak:AVG?
POWer:MODulation:RESult:LPEak:NPEak?
POWer:MODulation:RESult:LPEak:PPEak?
POWer:MODulation:RESult:LPEak:STDDev?
POWer:MODulation:RESult:LPEak:WFMCount?
POWer:MODulation:RESult:LPEak[:ACTual]?
Return values:
<ActualValue>
Usage: Query only
POWer:MODulation:RESult:MEAN[:ACTual]?
POWer:MODulation:RESult:MEAN:AVG?
POWer:MODulation:RESult:MEAN:NPEak?
