Remote control commands
R&S
®
RTM3000
769User Manual 1335.9090.02 ─ 09
Parameters:
<State> ON | OFF
*RST: OFF
DIGital<m>:PROBe[:ENABle]?
Tests whether the digital probe is connected and recognized by the instrument.
Suffix:
<m>
.
0..15
For pod 1: a value between 0 and 7
For pod 2: a value between 8 and 15
Return values:
<ProbeEnable> ON | OFF
Usage: Query only
DIGital<m>:DISPlay <State>
Enables and displays the indicated logic channel, or disables it.
Suffix:
<m>
.
0..15
Number of the logic channel
Parameters:
<State> ON | OFF
*RST: OFF
DIGital<m>:TECHnology <ThresholdMode>
Selects the threshold voltage for various types of integrated circuits and applies it to
the channel group to which the indicated logic channel belongs.
Suffix:
<m>
.
0..15
Number of the logic channel
Parameters:
<ThresholdMode> TTL | ECL | CMOS | MANual
TTL: 1.4 V
ECL: -1.3 V
CMOS: 2.5 V
MANual: Set a user-defined threshold value with DIGital<m>:
THReshold
*RST: MAN
Mixed signal option (option R&S RTM-B1)
