Identifying System Power Requirements
Workpoint Clients, Key Modules and Adapter Power Requirements
optiPoint 500
optiPoint 500 entry 0.3
optiPoint 500 economy (not for U.S.) 0.7
optiPoint 500 basic 0.7
optiPoint 500 standard,
optiPoint 500 standard SL (For U.S. Only)
0.7
optiPoint 500 advance 0.72
optiPoint key module 0.05
optiPoint BLF 0.0
2
optiPoint Analog Adapter 0.00
3
optiPoint ISDN Adapter 0.7
optiPoint Phone Adapter 0.18
optiPoint Acoustic Adapter 0.25
optiPoint Recorder Adapter 0.3
optiPoint 600 office 0.0
2
Table D-13 Workpoint Clients, Key Modules and Adapter Power Requirements
Workpoint Client Net Power Requirement in W
(from –48 V input)
