Identifying System Power Requirements
P31003-H3560-S403-54-7620, 09/05
D-14 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
power_calc.fm
Workpoint Clients, Key Modules and Adapter Power Requirements
optiset E
optiset E entry 0.36
optiset E basic 0.36
optiset E standard 0.41
optiset E advance plus/comfort 0.43
optiset E advance conference/conference 0.85
optiset E memory 0.56
optiset E key Module 0.06
Hicom Attendant BLF 0.0
2
optiset E acoustic adapter 0.02
optiset E analog adapter 0.0
3
optiset E contact adapter 0.7
optiset E control adapters 0.34
optiset E data adapter 0.76
optiset E headset adapter 0.03
optiset E headset plus adapter 0.23
optiset E ISDN adapter 0.05
optiset E phone adapter 0.06
Analog telephone (40 mA for short trunk) in active status 0.3
1 A local power supply is used for Power over LAN (in accordance with Cisco and the pre802.3af standard) and power supply.
2 Power is provided by a local power supply.
3 A local power supply provides power to the connected analog telephone.
Table D-13 Workpoint Clients, Key Modules and Adapter Power Requirements
Workpoint Client Net Power Requirement in W
(from –48 V input)
