Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-158 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
● HiPath 3550
Subject to certain prerequisites, the system-internal PSU UPSC-D provides sufficient pow-
er for the operation of sixteen BS3/1s (one U
P0/E
each) or eight BS2/2s and BS3/3s (two
U
P0/E
each). These prerequisites depend on the
– Line length and line type between SLC16N and base station.
The following specifications are based on line lengths of up to 1000 m and a line type
2x0.6 mm per U
P0/E
.
– Number and type of corded telephones connected to the system.
Table 3-65 through Table 3-67 show which telephone configurations work without ad-
ditional power supply.
Table 3-65 HiPath 3550 - Maximum Number of Corded Telephones Depending on the
Number of BS3/1 Base Stations Connected to SLC16N and BS4 connect-
ed to SLC16N (not for U.S)
Number
of BS3/1s and BS4s
connected via 1xU
P0/E
to
SLC16N
Maximum number of corded telephones
analog telephones
0 1 - 10 11 - 20 21 - 30 31 - 40 41 - 50
optiset E and optiPoint 500 telephones
1 666157534844
2 635954504641
3 605652474339
4 585349454036
5 555147423833
6 534844403531
7 504641373328
8 474339343026
9 454036322723
10 42 38 33 29 25 20
11 40 35 31 27 22 18
12 37 33 28 24 20 15
13 34 30 26 21 17 13
14 32 27 23 19 14 10
15 29 25 20 16 12 7
16 27 22 18 13 9 5
