Boards for HiPath 3000
P31003-H3560-S403-54-7620, 09/05
3-260 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
boards.fm
Peripheral Boards
LED statuses and their meanings
Table 3-114 TIEL - LED Statuses
LED Status
(on/off)
Meaning Action
During Startup and Initialization
Flickering (50/50
ms)
Board test unsuccessful Replace board.
Flashing (100/
100 ms)
Board not configured Inspect visually, remove and re-insert
board if necessary.
Replace board if flashing continues.
On Loading in progress
Flashing (100/
100 ms)
Code could not be loaded Replace board.
Off Board loaded
Flashing (500/
500 ms)
Board loaded but not yet activated
During Operation
On Circuit seized
Flashing in ring
cadence
Circuit in ringing state
Flickering (450/
50 ms)
Dependability test (loopback test)
in progress
Flashing (500/
500 ms)
Circuit out of service (e.g. S1/x in
“on” position”)
Check whether the circuit was deacti-
vated with HiPath 3000 Manager E or
lockout switch.
Off Circuit is idle, no seizure
