Installing HiPath 3000
P31003-H3560-S403-54-7620, 09/05
4-62 HiPath 3000 V6.0, HiPath 5000 V6.0, Provisional Service Manual
inst_h3.fm
Installing HiPath 3800
Information on cable and connector assignment is provided in the board descriptions in
Chapter 3.
Slot with
SLCN
SLMA
SLMA2
1
SLMA8
SLMO2
SLMO8
TM2LP
TMC16
1
TMDID
2
Connector panel with 24 RJ45 jacks: S30807-Q6622-X
The RJ45 jacks are configured with two wires.
different or no
assignment
The backplane sections of other boards and empty board slots must be cov-
ered with filler panels.
1 for selected countries only
2for U.S. only
