B3: Distributed systems - 840D sl only
2.2 NCU link
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
103
Synchronization with axis position
If the new container axis assigned to the channel after a container rotation does not have the
same absolute machine position as the previous axis, then the container is synchronized
with the new position (internal REORG).
Note
SD41700 $SN_AXCT
_SWWIDTH[<axis container>] is only upd
ated for
a new configuration. If, after incremental rotation of the RTM/MS, the position of a circuit before the initial position
is reached, the container can be rotated normally in the forward direction to reach the initial
position of the container again. The drum or rotary table must however be turned back to the
original position, so that measuring and supply cables are not twisted.
See also
System variable (Page 111)
Programming (Page 110)
2.2.4.2 Parameterization
Machine data
NC-specific machine data
Number Identifier $MN_ Meaning
MD12750 AXCT_NAME_TAB Name of the axis container
MD12760 AXCT_FUNCTION_MASK.Bit x Axis container-specific functions
MD1270x AXCT_AXCONF_ASSIGN_TABx Assignment of machine axes to the slots of an axis container
MD18720 MM_SERVO_FIFO_SIZE Size of the IPO/SERVO data buffer
Note:
The value 3 must be set on all participating NCUs for cross-NCU axis
containers.
Name of the axis container
MD12750 $MN_AXCT_NAME_TAB[ <index> ] = "<name>"
Parameters Meaning
<index>: 0, 1, … max. axis container index
<name>: Name of the axis container (e.g. CT1)
