Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
835
Z2: NC/PLC interface signals
18
18.1 Digital and analog NCK I/Os (A4)
18.1.1 Signals to NC (DB10)
Overview of signals from PLC to NC
DB10 Signals to NC interface PLC → NC
DBB Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Disable digital NCK inputs
Digital inputs without hardware *) (on-board inputs) **)
Input 8 Input 7 Input 6 Input 5 Input 4 Input 3 Input 2 Input 1
1 Setting by PLC of the digital NCK inputs
Digital inputs without hardware *) (on-board inputs) **)
Input 8 Input 7 Input 6 Input 5 Input 4 Input 3 Input 2 Input 1
4 Disable digital NCK outputs
Digital outputs without hardware *) on-board outputs **)
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
5 Overwrite screen form for digital NCK outputs
Digital outputs without hardware *) on-board outputs **)
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
6 Set value by PLC of the digital NCK outputs
Digital outputs without hardware *) on-board outputs **)
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
7 Setting screen form for digital NCK outputs
Digital outputs without hardware *) on-board outputs **)
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
Notes:
*) Bits 4 to 7 of the digital NCK inputs/outputs can be processed by the PLC even though there are no equivalent hardware
I/Os. These bits can therefore also be used for data exchange between the NCK and PLC.
**) The NCK digital inputs/outputs 1 to 4 are provided as onboard hardware inputs and outputs.
DB10 Signals to NC interface PLC → NC
DBB Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
122 Disable digital NCK inputs
Input 16 Input 15 Input 14 Input 13 Input 12 Input 11 Input 10 Input 9
123 Setting by PLC of the digital NCK inputs
Input 16 Input 15 Input 14 Input 13 Input 12 Input 11 Input 10 Input 9
