Siemens SINUMERIK Series Function Manual

K3: Compensations
4.4 Interpolatory compensation
Extended Functions
264 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
4.4.4.3 Example
The direction-dependent compensation tables of the X axis are shown in detail for a three-
axis machine in the fallowing example:
Configuring
Number of compensation interpolation points:
MD18342 $MN_MM_CEC_MAX_POINTS[0] = 11 (Table 1: Axis X, positive traversing
direction)
MD18342 $MN_MM_CEC_MAX_POINTS[1] = 11 (Table 2: Axis X, negative traversing
direction)
Note
It is not necessary to define the number of interpolation points for SINUMERIK 828D,
because when enabling the "sag compensation, multi-dimensional" option, immediately eight
tables each with 200 interpolation points per table for the compensation are available. This
cannot be extended!
Interpolation points
Table <t> [0,<N>]
Number of
interpolation points
MD18342 $MN_MM_CEC_MAX_POINTS[0] = 11
Interpolation point
<N>
0 1 2 3 4 5 6 7 8 9 10
Position X -585 -527 -469 -411 -353 -295 -237 -179 -121 -63 -5
