Siemens SINUMERIK Series Function Manual

K3: Compensations
4.8 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
303
4.8.2.2 Axis/spindle-specific setting data
Number Identifier: $SA_ Description
43900 TEMP_COMP_ABS_VALUE Position-independent temperature compensation
value
43910 TEMP_COMP_SLOPE Gradient for position-dependent temperature
compensation
43920 TEMP_COMP_REF_POSITION Reference position for position-dependent
temperature compensation
4.8.3 Signals
4.8.3.1 Signals from NC
Signal name SINUMERIK 840D sl SINUMERIK 828D
NC Ready DB10.DBX108.7 DB2700.DBX2.7
4.8.3.2 Signals from mode group
Signal name SINUMERIK 840D sl SINUMERIK 828D
Mode group ready DB11.DBX6.3 DB3100.DBX0.3
4.8.3.3 Signals from channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
Channel ready DB21, ... .DBX36.5 DB3300.DBX4.5
4.8.3.4 Signals to axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Activate dynamic backlash compensation DB31, ... .DBX25.0 DB380x.DBX5001.0
