3.10 Start-up: Handwheels
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
201
3.10.2 Connection via PPU (only 828D)
Parameter assignment
Handwheels directly connected to terminal X143 of the PPU are parameterized using the
following NCK machine data:
● MD11350 $MN_HANDWHEEL_SEGMENT[<
Handwheel_No._in_NCK - 1
>] = 2
When directly connected to the PPU, a 2 (8xxD_HW) must always be entered as
handwheel segment.
● MD11351 $MN_HANDWHEEL_MODULE[<
Handwheel_No._in_NCK - 1
>] = 1
When directly connected to the PPU, a 1 must always be entered.
● MD11352 $MN_HANDWHEEL_INPUT[<
Handwheel_No_in_NCK - 1
>] = <
Handwheel
connection
>
The number of the handwheel has to be entered: 1 or 2
Note
Two handwheels can be connected to a PPU (terminal X143).
Example
Parameter assignment of two handwheels connected via terminal X143 of the PPU.
Machine data Value Meaning
1st handwheel:
MD11350 $MN_HANDWHEEL_SEGMENT[0] 2 Hardware segment: 8xxD_HW
MD11351 $MN_HANDWHEEL_MODULE[0] 1 ---
MD11352 $MN_HANDWHEEL_INPUT[0] 1 1st handwheel connection of X143
2nd handwheel:
MD11350 $MN_HANDWHEEL_SEGMENT[1] 2 Hardware segment: 8xxD_HW
MD11351 $MN_HANDWHEEL_MODULE[1] 1 ---
MD11352 $MN_HANDWHEEL_INPUT[1] 2 2nd handwheel connection of X143
