Siemens SINUMERIK Series Function Manual

N4: Own channel - only 840D sl
9.9 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
597
9.9.3 Signals
9.9.3.1 Signals to channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
No stroke enable DB21, ... .DBX3.0 -
Manual stroke initiation DB21, ... .DBX3.1 -
Stroke suppression DB21, ... .DBX3.2 -
Stroke inoperative DB21, ... .DBX3.3 -
Delayed stroke DB21, ... .DBX3.4 -
Manual stroke initiation DB21, ... .DBX3.5 -
9.9.3.2 Signals from channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
Stroke initiation active DB21, ... .DBX38.0 -
Acknowledgement of manual stroke initiation DB21, ... .DBX38.1 -
9.9.4 Language commands
G group Language
command
Meaning
35
SPOF
Stroke / Punch OFF Punching and nibbling OFF
35
SON
Stroke ON Nibbling ON
35
SONS
Stroke ON Nibbling ON (position controller)
35
PON
Punch ON Punching ON
35
PONS
Punch ON Punching ON (position controller)
36
PDELAYON
Punch with Delay ON Punching with delay ON
36
PDELAYOF
Punch with Delay OFF Punching with delay OFF
Path segmentation
SPP
Path per stroke, modal action
SPN
Number of strokes per block, non-modal action
