Siemens SINUMERIK Series Function Manual

P5: Oscillation - only 840D sl
11.6 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
677
11.6.2 Setting data
11.6.2.1 Axis/spindle-specific setting data
Number Identifier: $SA_ Description
43700 OSCILL_REVERSE_POS1 Position at reversal point 1
43710 OSCILL_REVERSE_POS2 Position at reversal point 2
43720 OSCILL_DWELL_TIME1 Stop time at reversal point 1
43730 OSCILL_DWELL_TIME2 Stop time at reversal point 2
43740 OSCILL_VELO Feed velocity of oscillation axis
43750 OSCILL_NUM_SPARK_CYCLES Number of sparking-out strokes
43760 OSCILL_END_POS Position after sparking-out strokes/at end of oscillation
movement
43770 OSCILL_CTRL_MASK Control screen form for oscillation
43780 OSCILL_IS_ACTIVE Oscillation movement ON/OFF
43790 OSCILL_START_POS Position that is approached after oscillation before reversal
point 1, if activated in SD43770:
11.6.3 Signals
11.6.3.1 Signals to axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
External oscillation reversal DB31, ... .DBX28.0 -
Set reversal point DB31, ... .DBX28.3 -
Alter reversal point DB31, ... .DBX28.4 -
Stop at next reversal point DB31, ... .DBX28.5 -
Stop along braking ramp DB31, ... .DBX28.6 -
PLC-controlled axis DB31, ... .DBX28.7 -
11.6.3.2 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Oscillation reversal is active DB31, ... .DBX100.2 -
Oscillation cannot start DB31, ... .DBX100.3 -
Error during oscillation movement DB31, ... .DBX100.4 -
Sparking-out active DB31, ... .DBX100.5 -
