Page #828 background image
W4: Grinding-specific tool offset and tool monitoring
17.4 Grinding-specific tool monitoring
Extended Functions
828 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
When is the speed limit value recalculated?
The speed limit value is recalculated:
when the monitoring function is selected,
when the online offset values (wear parameters) are altered.
Monitor reactions
The system reacts as follows when the speed monitor responds:
The speed is restricted to the limit value
and
Interface signal:
DB31, ... DBX83.6 (speed monitoring)
is output.
DB31, ... DBX83.6 = 1 ⇒ Speed monitoring limit reached
DB31, ... DBX83.6 = 0 ⇒ Speed monitoring limit not reached
Note
No error reaction is initiated internally in the control system.
17.4.4 Selection/deselection of tool monitoring
Part program commands
The following part program commands are provided for selecting and deselecting the
grinding-specific tool monitor of an active or inactive tool:
Command Meaning
TMON
Tool monitoring ON
Selection of tool monitoring for the active tool in the channel.
TMOF
Tool monitoring OFF
Deselection of tool monitoring for the active tool in the channel.
TMON (T number)
Tool monitoring ON (T No.)
Selection of tool monitoring for a non-active tool with T number.
TMOF (T number)
Tool monitoring OFF (T No.)
Deselection of tool monitoring for a non-active tool with T number.
TMOF (0)
Tool monitoring OFF (0)
Deselection of tool monitoring for all tools.
