11.5.4 Examples for starting position
11.5.4.1 Define starting position via language command
Program code Comment
WAITP(Z) ; enable oscillation for the Z axis
OSP1[Z]=10 OSP2[Z]=60 ; explain reversal points 1 and 2
OST1[Z]=-2 OST2[Z]=0 ; Reversal point 1: without exact stop
; Reversal point 2: Exact stop fine
FA[Z]=5000 FA[X]=2000 ; Infeed for oscillating axis,
; feedrate for infeed axis
OSCTRL[Z]=(1+8+16,0) ; Switch off oscillation motion at reversal point 1
; after delete DTG spark-out and approach end position,
; After DTG, approach relevant reversal position
;
OSNSC[Z]=3 ; 3 sparking-out strokes
OSE[Z]=0 ; End position = 0
OSB[Z]=0 ; Start position = 0
OS[Z]=1 X15 F500 ; Start oscillation, continuous infeed
OS[Z]=0 ; Deactivate oscillation
WAITP(Z) ; wait for completion of the oscillation motion
M30
Explanation
When the Z axis starts oscillation, it first approaches the starting position (position = 0 in the
example) and then begins the oscillation motion between the reversal points 10 and 60.
When the X axis has reached its end position 15, the oscillation finishes with 3 sparking out
strokes and approach of end position 0.
11.5.4.2 Start oscillation via setting data
Program code Comment
WAITP(Z)
STOPRE
$SA_OSCILL_REVERSE_POS1[Z]=-10 ; reversal position 1 = -10
$SA_OSCILL_REVERSE_POS2[Z]=30 ; reversal position 2 = 30
$SA_OSCILL_START_POS[Z] = -50 ; Start position = -50
$SA_OSCILL_CTRL_MASK[Z] = 512 ; Approach start position,
; on switch-off, stop at the next
; reversal point
; do not approach any end position
; no sparking-out strokes for DTG
