K5: Mode groups, channels, axis interchange
5.6 Data lists
Extended Functions
346 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
5.6.2 Setting data
5.6.2.1 Channelspecific setting data
Number Identifier: $SC_ Description
42000 THREAD_START_ANGLE Start angle for thread
42100 DRY_RUN_FEED Dry run feedrate
5.6.3 Signals
5.6.3.1 Signals to/from BAG
The mode group signals from the PLC to the NCK and from the NCK to the PLC are included
in data block 11.
The signals are described in:
Reference:
Function Manual, Basic Functions; NC/PLC Interface Signals (Z1),
Chapter "Mode group, Program Operation (K1)"
5.6.3.2 Signals to/from Channel
The channel signals from the PLC to the NCK and from the NCK to the PLC are included in
data blocks 21, 22, ... for the first, second ... channel.
The signals are described in:
Reference:
Function Manual, Basic Functions; NC/PLC Interface Signals (Z1),
Chapter "Mode group, Program Operation (K1)"
