Siemens SINUMERIK Series Function Manual

Z2: NC/PLC interface signals
18.8 Software cams, position switching signals (N3)
Extended Functions
890 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
18.8.3 Signals to axis/spindle (DB31, ...)
DB31, ...
DBX2.0 Cam activation
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
Output of the minus and plus cam signals of an axis to the general PLC interface is activated.
The activation takes effect immediately after processing of IS "Cam activation".
Signal state 0 or
edge change 1 → 0
The minus and plus cam signals of an axis are not output to the general PLC interface.
Corresponding to .... DB10 DBX110.0 - 113.7 (minus cam signal 1-32)
DB10 DBX114.0 - 117.7 (plus cam signals 1-32)
18.8.4 Signals from axis/spindle (DB31, ...)
DB31, ...
DBX62.0 Cams active
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
All cams of the axis selected via NC/PLC interface signal:
DB31, ... DBX2.0 (Cam activation)
have been activated successfully.
Signal state 0 or
edge change 1 → 0
The cams of the axis are not activated.
Corresponding to .... DB31, ... DBX2.0 (Cam activation)
DB10 DBX110.0 - 113.7 (minus cam signal 1-32)
DB10 DBX114.0 - 117.7 (plus cam signals 1-32)

Siemens SINUMERIK Series Specifications

General

Axes Control	Up to 31 axes
Category	Control Unit
Manufacturer	Siemens
Series	SINUMERIK
Control Type	CNC
Communication Interfaces	Ethernet, USB
Operating Temperature	0°C to 45°C
Protection Class	IP20
Power Supply	24V DC
Display	Color TFT LCD
