S7: Memory configuration
14.5 Data lists
Extended Functions
764 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
14.5 Data lists
14.5.1 Machine data
14.5.1.1 General machine data
Number Identifier: $MN_ Description
10134 MM_NUM_MMC_UNITS Number of simultaneous HMI communication partners
10850 MM_EXTERN_MAXNUM_OEM_GCODES Maximum number of OEM-G codes
10880 MM_EXTERN_CNC_SYSTEM Definition of the control system to be adapted
10881 MM_EXTERN_GCODE_SYSTEM ISO_3 Mode: GCodeSystem
18050 INFO_FREE_MEM_DYNAMIC Free-dynamic-memory display data
18060 INFO_FREE_MEM_STATIC Free-static-memory display data
18070 INFO_FREE_MEM_DPR Display data for free memory in
dual-port RAM
18072 INFO_FREE_MEM_CC_MD Displays memory available in the CC-MD memory
18078 MM_MAX_NUM_OF_HIERARCHIES Maximum number of definable magazine-location-
type hierarchies
18079 MM_MAX_HIERARCHY_ENTRIES Maximum permissible number of entries in a
magazine-location-type hierarchy
18080 MM_TOOL_MANAGEMENT_MASK Mask for reserving memory for tool management
18082 MM_NUM_TOOL Number of tools managed by NCK
18084 MM_NUM_MAGAZINE Number of magazines managed by NCK
18086 MM_NUM_MAGAZINE_LOCATION Number of magazine locations
18088 MM_NUM_TOOL_CARRIER Maximum number of definable toolholders
18090 MM_NUM_CC_MAGAZINE_PARAM Compile-cycle tool management:
quantity of magazine data
18092 MM_NUM_CC_MAGLOC_PARAM Compile-cycle tool management:
quantity of magazine-location data
18094 MM_NUM_CC_TDA_PARAM Compile-cycle tool management: quantity of TDA data
18096 MM_NUM_CC_TOA_PARAM Compile-cycle tool management: quantity of TOA data
18098 MM_NUM_CC_MON_PARAM Compile-cycle tool management:
quantity of monitor data
18100 MM_NUM_CUTTING_EDGES_IN_TOA Number of tool offsets in NCK
18102 MM_TYPE_OF_CUTTING_EDGE Type of D-number programming
18104 MM_NUM_TOOL_ADAPTER Tool adapter in TO area
18105 MM_MAX_CUTTING_EDGE_NO Maximum value of D number
18106 MM_MAX_CUTTING_EDGE_PERTOOL Maximum number of D numbers per tool
18108 MM_NUM_SUMCORR Additive offsets in the TO area
