Page #220 background imageLoading...
Page #220 background image
H1: Manual and handwheel travel
3.12 Data lists
Extended Functions
220 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
Signal name SINUMERIK 840D sl SINUMERIK 828D
Orientation axis 2: Traversing keys minus/plus DB21, ... .DBX324.6-7 -
Orientation axis 2:
Machine function 1 INC ... Var. INC
DB21, ... .DBX325.0-5
-
Orientation axis 2: Invert handwheel direction of rotation DB21, ... .DBX327.0 -
Orientation axis 3: Activate handwheel DB21, ... .DBX328.0-2 -
Orientation axis 3: Traversing key lock DB21, ... .DBX328.4 -
Orientation axis 3: Rapid traverse override DB21, ... .DBX328.5 -
Orientation axis 3: Traversing keys minus/plus DB21, ... .DBX328.6-7 -
Orientation axis 3:
Machine function 1 INC ... Var. INC
DB21, ... .DBX329.0-5
-
Orientation axis 3: Invert handwheel direction of rotation DB21, ... .DBX331.0 -
3.12.3.5 Signals from channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
DRF selected DB21, ... .DBX24.3 DB1700.DBX0.3
Handwheel override active (path axes) DB21, ... .DBX33.3 DB3300.DBX1.3
Contour handwheel active DB21, ... .DBX37.0-2 DB3300.DBX5.0-2
Invert contour handwheel direction of rotation active DB21, ... .DBX39.5 DB3300.DBX7.5
Handwheel active DB21, ... .DBX40.0-2 DB3300.DBX1000.0-1
Traversing requests minus/plus DB21, ... .DBX40.4-5 DB3300.DBX1000.4-5
Traversing command minus/plus DB21, ... .DBX40.6-7 DB3300.DBX1000.6-7
Active machine function 1 INC ...
Var. INC
DB21, ... .DBX41.0-5
DB3300.DBX1001.0-5
Geometry axis 1
Handwheel direction of rotation
inversion active
DB21, ... .DBX43.0
DB3300.DBX1003.0
Handwheel active DB21, ... .DBX46.0-2 DB3300.DBX1004.0-1
Traversing requests minus/plus DB21, ... .DBX46.4-5 DB3300.DBX1004.4-5
Traversing command minus/plus DB21, ... .DBX46.6-7 DB3300.DBX1004.6-7
Active machine function 1 INC ...
Var. INC
DB21, ... .DBX47.0-5
DB3300.DBX1005.0-5
Geometry axis 2
Handwheel direction of rotation
inversion active
DB21, ... .DBX49.0
DB3300.DBX1007.0
Handwheel active DB21, ... .DBX52.0-2 DB3300.DBX1008.0-1
Traversing requests minus/plus DB21, ... .DBX52.4-5 DB3300.DBX1008.4-5
Traversing command minus/plus DB21, ... .DBX52.6-7 DB3300.DBX1008.6-7
Active machine function 1 INC ...
Var. INC
DB21, ... .DBX53.0-5
DB3300.DBX1009.0-5
Geometry axis 3
Handwheel direction of rotation
inversion active
DB21, ... .DBX55.0
DB3300.DBX1011.0
