Siemens SINUMERIK Series Function Manual

S3: Synchronous spindle
13.7 Data lists
Extended Functions
752 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
13.7.3 Signals
13.7.3.1 Signals to channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
NC Start DB21, ... .DBX7.1 DB3200.DBX7.1
NC Stop axes plus spindle DB21, ... .DBX7.4 DB3200.DBX7.4
13.7.3.2 Signals from channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
Dry run feedrate selected DB21, ... .DBX24.6 DB1700.DBX0.6
Feedrate override selected for rapid traverse DB21, ... .DBX25.3 DB1700.DBX1.3
13.7.3.3 Signals to axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Axis/spindle disable DB31, ... .DBX1.3 DB380x.DBX1.3
Follow-up mode DB31, ... .DBX1.4 DB380x.DBX1.4
Position measuring system 1, position measuring system
2
DB31, ... .DBX1.5/6 DB380x.DBX1.5/6
Controller enable DB31, ... .DBX2.1 DB380x.DBX2.1
Distance-to-go/Spindle RESET DB31, ... .DBX2.2 DB380x.DBX2.2
Spindle stop/feed stop DB31, ... .DBX4.3 DB380x.DBX4.3
Traversing keys for JOG DB31, ... .DBX4.6/7 DB380x.DBX4.6/7
Re-synchronize spindle 1, re-synchronize spindle 2 DB31, ... .DBX16.4/5 DB380x.DBX2000.4/5
Delete S value DB31, ... .DBX16.7 DB380x.DBX2000.7
Feedrate override valid DB31, ... .DBX17.0 DB380x.DBX2001.0
Invert M3/M4 DB31, ... .DBX17.6 DB380x.DBX2001.6
Spindle override DB31, ... .DBB19 DB380x.DBB2003
Re-synchronizing DB31, ... .DBX31.4 -
Disable synchronization DB31, ... .DBX31.5 -
