W3: Tool change
16.9 Data lists
Extended Functions
800 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
16.9 Data lists
16.9.1 Machine data
16.9.1.1 General machine data
Number Identifier: $MN_ Description
18082 MM_NUM_TOOL Number of tools
16.9.1.2 Channelspecific machine data
Number Identifier: $MC_ Description
22200 AUXFU_M_SYNC_TYPE Output timing of M functions
22220 AUXFU_T_SYNC_TYPE Output timing of T functions
22550 TOOL_CHANGE_MODE New tool offset for M function
22560 TOOL_CHANGE_M_CODE M function for tool change
16.9.1.3 Axis-/spindlespecific machine data
Number Identifier: $MA_ Description
30600 FIX_POINT_POS[n]. Fixed point positions of the machine axes for G75
16.9.2 Signals
16.9.2.1 Signals from channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
M function M06 DB21, ... .DBX194.6 DB2500.DBB1000.6
