Siemens SINUMERIK Series Function Manual

Z2: NC/PLC interface signals
18.12 Rotary axes (R2)
Extended Functions
902 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
18.12 Rotary axes (R2)
18.12.1 Signals to axis/spindle (DB31, ...)
DB31, ...
DBX12.4 Traversing range limitation for modulo rotary axes
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
Activate traversing range limitation for modulo rotary axes
(software end switches, work field limitations).
Signal state 0 or
edge change 1 → 0
Deactivate traversing range limitation for modulo rotary axes.
Signal irrelevant for
...
Linear axes / rotary axes without modulo functionality.
Application
example(s)
Built-on rotary axis with monitoring
18.12.2 Signals from axis/spindle (DB31, ...)
DB31, ...
DBX74.4 Monitoring status with modulo rotary axes
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
Traversing range limitation for modulo rotary axes active
(software end switches, work field limitations).
Signal state 0 or
edge change 1 → 0
Traversing range limitation for modulo rotary axes not active.
Signal irrelevant for
...
Linear axes / rotary axes without modulo functionality.
Application
example(s)
Built-on rotary axis with monitoring
