Siemens SINUMERIK Series Function Manual

Z2: NC/PLC interface signals
18.11 Oscillation (P5)
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
901
DB31, …
DBX100.5 Sparking-out active
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The axis is executing sparking-out strokes.
Signal state 0 or edge
change 1 → 0
The axis is not currently executing sparking-out strokes.
Corresponding to .... DBX100.7
DB31, ...
DBX100.6 Oscillation movement active
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The axis is executing an oscillation movement between 2 reversal points.
Signal state 0 or edge
change 1 → 0
The axis is not currently oscillating.
Signal irrelevant
for ......
DBX100.7 = 0
Corresponding to .... DBX100.7
DB31, ...
DBX100.7 Oscillation active
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The axis is currently being traversed as an oscillation axis.
Signal state 0 or edge
change 1 → 0
The axis is a positioning axis.
Corresponding to .... DBX100.5, DBX100.6
DB31, ...
DBX104.0 - 7 Active infeed axes
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or edge
change 0 → 1
The axis sending the signal is currently the oscillation axis and is indicating its active infeed
axes in this field (104.0 axis 1 is infeed axis, 104.1 axis 2 is infeed axis, etc.).
Signal state 0 or edge
change 1 → 0
The associated axis is not an infeed axis.
Corresponding to .... DBX100.7
