H1: Manual and handwheel travel
3.3 Incremental (JOG INC)
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
153
● When the first valid limit is reached
CAUTION
Traversing range limit inactive
Software limit switches and working-area limitations are only activated after reference
point approach.
● Deselection or change of the current increment (e.g. change from INC100 to INC10)
● When faults occur (e.g. on cancellation of the servo enable)
WARNING
Risk of collision
If "continuous" mode is selected, several axes can by started by pressing and releasing the
relevant direction key. Any interlocks must be implemented via the PLC!
Note
While an axis is moving, a change of mode from JOG to AUTOMATIC or MDI is not
permitted within the control.
Parameter assignment
The selection of jog or continuous mode is performed NC-specifically for all axes via the
machine data:
MD11300 $MN_JOG_INC_MODE_LEVELTRIGGRD (INC and REF in jog mode)
Jogging mode is the default setting.
3.3.3 Supplementary conditions
Indexing axis
Irrespective of the set increment value, an indexing axis traverses to the next indexing
position in the direction of travel after pressing the traversing key (see Section "T1: Indexing
axe
s (Page 771)").
