Siemens SINUMERIK Series Function Manual

T1: Indexing axes
15.9 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
793
15.9 Data lists
15.9.1 Machine data
15.9.1.1 General machine data
Number Identifier: $MN_ Description
10260 CONVERT_SCALING_SYSTEM Basic system switchover active
10270 POS_TAB_SCALING_SYSTEM System of measurement of position tables
10900 INDEX_AX_LENGTH_POS_TAB_1 Number of positions for indexing axis table 1
10910 INDEX_AX_POS_TAB_1[n] Indexing position table 1
10920 INDEX_AX_LENGTH_POS_TAB_2 Number of positions for indexing axis table 2
10930 INDEX_AX_POS_TAB_2[n] Indexing position table 2
10940 INDEX_AX_MODE Options for indexing positions
15.9.1.2 Axis/spindlespecific machine data
Number Identifier: $MA_ Description
30300 IS_ROT_AX Rotary axis
30310 ROT_IS_MODULO Modulo conversion for rotary axis
30320 DISPLAY_IS_MODULO Position display is modulo 360°
30500 INDEX_AX_ASSIGN_POS_TAB Axis is indexing axis
30501 INDEX_AX_NUMERATOR Numerator for indexing axes with equidistant positions
30502 INDEX_AX_DENOMINATOR Denominator for indexing axes with equidistant
positions
30503 INDEX_AX_OFFSET Indexing position for indexing axes with equidistant
positions
30505 HIRTH_IS_ACTIVE Hirth tooth system is active
15.9.2 Setting data
15.9.2.1 General setting data
Number Identifier: $SN_ Description
41050 JOG_CONT_MODE_LEVELTRIGGRD JOG continuous in inching mode
