N4: Own channel - only 840D sl
9.9 Data lists
Extended Functions
596 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
9.9 Data lists
9.9.1 Machine data
9.9.1.1 General machine data
Number Identifier: $MN_ Description
11450 SEARCH_RUN_MODE Block search parameter settings
9.9.1.2 Channelspecific machine data
Number Identifier: $MC_ Description
20150 GCODE_RESET_VALUES[n] Reset G groups
26000 PUNCHNIB_ASSIGN_FASTIN Hardware assignment for input-byte with stroke
control
26002 PUNCHNIB_ASSIGN_FASTOUT Hardware assignment for output-byte with stroke
control
26004 NIBBLE_PUNCH_OUTMASK[n]) Mask for quick output bits
26006 NIBBLE_PUNCH_INMASK[n] Mask for quick input bits
26008 NIBBLE_PUNCH_CODE[n] Determination of the M functions
26010 PUNCHNIB_AXIS_MASK Definition of punching and nibbling axes
26012 PUNCHNIB_ACTIVATION Activation of punching and nibbling functions
26014 PUNCH_PATH_SPLITTING Activation of automatic path segmentation
26016 PUNCH_PARTITION_TYPE Behavior of single axes with active automatic path
segmentation
26018 NIBBLE_PRE_START_TIME Automatically activated pre-initiation time
26020 NIBBLE_SIGNAL_CHECK Monitoring of the input signal
9.9.2 Setting data
9.9.2.1 Channelspecific setting data
Number Identifier: $SC_ Description
42400 PUNCH_DWELL_TIME Dwell time
42402 NIBPUNCH_PRE_START_TIME Pre-start time
42404 MINTIME_BETWEEN_STROKES Minimum time interval between two consecutive
strokes
