Siemens SINUMERIK Series Function Manual

Z2: NC/PLC interface signals
18.1 Digital and analog NCK I/Os (A4)
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
843
18.1.2 Signals from NC (DB10)
Overview of signals from NC to PLC
DB10 Signals from NC interface NC → PLC
DBB Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
60 Actual value for digital NCK inputs
(on-board inputs) **)
Input 4 Input 3 Input 2 Input 1
64 Setpoint for digital NCK outputs
Digital inputs without hardware *) on-board outputs **)
Output 8 Output 7 Output 6 Output 5 Output 4 Output 3 Output 2 Output 1
186 Actual value for digital NCK inputs
Input 16 Input 15 Input 14 Input 13 Input 12 Input 11 Input 10 Input 9
187 Actual value for digital NCK inputs
Input 24 Input 23 Input 22 Input 21 Input 20 Input 19 Input 18 Input 17
188 Actual value for digital NCK inputs
Input 32 Input 31 Input 30 Input 29 Input 28 Input 27 Input 26 Input 25
189 Actual value for digital NCK inputs
Input 40 Input 39 Input 38 Input 37 Input 36 Input 35 Input 34 Input 33
190 Setpoint for digital NCK outputs
Output
16
Output 15 Output 14 Output 13 Output 12 Output 11 Output 10 Output 9
191 Setpoint for digital NCK outputs
Output
24
Output 23 Output 22 Output 21 Output 20 Output 19 Output 18 Output 17
192 Setpoint for digital NCK outputs
Output
32
Output 31 Output 30 Output 29 Output 28 Output 27 Output 26 Output 25
193 Setpoint for digital NCK outputs
Output
40
Output 39 Output 38 Output 37 Output 36 Output 35 Output 34 Output 33
Notes:
*) Bits 4 to 7 of the digital inputs and NCK outputs can be processed by the PLC although no
equivalent hardware I/Os exist. These bits can therefore also be used for data exchange between the
NCK and PLC.
**) The NCK digital inputs/outputs 1 to 4 are provided as onboard hardware inputs and outputs.
DB10 Signals from NC interface NC → PLC
DBB Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
194,
195
Actual value for analog input 1 of NCK
196,
197
Actual value for analog input 2 of NCK
198,
199
Actual value for analog input 3 of NCK
