Page #554 background imageLoading...
Page #554 background image
N3: Software cams, position switching cycles - only 840D sl
8.6 Data lists
Extended Functions
554 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
8.6.2 Setting data
8.6.2.1 General setting data
Number Identifier: $SN_ Description
41500 SW_CAM_MINUS_POS_TAB_1[n] Position of minus cams 1 -8
41501 SW_CAM_PLUS_POS_TAB_1[n] Position of plus cams 1 -8
41502 SW_CAM_MINUS_POS_TAB_2[n] Position of minus cams 9 -16
41503 SW_CAM_PLUS_POS_TAB_2[n] Position of plus cams 9 -16
41504 SW_CAM_MINUS_POS_TAB_3[n] Position of minus cams 17 -24
41505 SW_CAM_PLUS_POS_TAB_3[n] Position of plus cams 17 -24
41506 SW_CAM_MINUS_POS_TAB_4[n] Position of minus cams 25 -32
41507 SW_CAM_PLUS_POS_TAB_4[n] Position of plus cams 25 -32
41520 SW_CAM_MINUS_TIME_TAB_1[n] Lead or delay time on minus cams 1 -8
41521 SW_CAM_PLUS_TIME_TAB_1[n] Lead or delay time on plus cams 1 -8
41522 SW_CAM_MINUS_TIME_TAB_2[n] Lead or delay time on minus cams 9 -16
41523 SW_CAM_PLUS_TIME_TAB_2[n] Lead or delay time on plus cams 9 -16
41524 SW_CAM_MINUS_TIME_TAB_3[n] Lead or delay time on minus cams 17 -24
41525 SW_CAM_PLUS_TIME_TAB_3[n] Lead or delay time on plus cams 17 -24
41526 SW_CAM_MINUS_TIME_TAB_4[n] Lead or delay time on minus cams 25 -32
41527 SW_CAM_PLUS_TIME_TAB_4[n] Lead or delay time on plus cams 25 -32
8.6.3 Signals
8.6.3.1 Signals to axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Cam activation DB31, ... .DBX2.0 -
8.6.3.2 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Cams active DB31, ... .DBX62.0 -
