M5: Measurement
7.9 Data lists
Extended Functions
532 Function Manual, 03/2013, 6FC5397-1BP40-3BA1
Program code Comment
N10 DEF REAL MESSWERT_IN_X[10]
N15 G17 T1 D1 ; Initial conditions,
: Tool compensation
; preselect for probe
N20 _ANF: G0 X0 F150 ← ; Prepositioning in the measured axis
N25 MEAS=+1 G1 X100 ← ; at 1st measurement input when
; switching signal not deflected,
; deflected in the X axis
N30 STOPRE ← ; Stop decoding for this after
; subsequent evaluation of
; results
N35 SIGNAL= $AC_MEA[1] ; read software switching signal at
; 1. Read measuring input
N37 IF SIGNAL == 0 GOTOF_FEHL1 ; Check switching signal
N40 MESSWERT_IN_X[II]=$AA_MW[X] ; Read measured value in workpiece
coordinates
N50 II=II+1
N60 IF II<10 GOTOB_ANF ; Repeat 10 times
N65 M0
N70 M02
N80 _FEHL1: MSG ("Probe not switching")
N90 M0
N95 M02
After the parameter display (user-defined variables) has been selected, the measurement
results can be read in field MEASVALUE_IN_X[10] provided that the program is still being
processed.
7.9 Data lists
7.9.1 Machine data
7.9.1.1 General machine data
Number Identifier: $MN_ Meaning
13200 MEAS_PROBE_LOW_ACTIVE Switching characteristics of probe
13201 MEAS_PROBE_SOURCE Measuring pulse simulation via digital output
13210 MEAS_TYPE Type of measurement for PROFIBUS DP drives
13211 MEAS_CENTRAL_SOURCE Central measuring data source with PROFIBUS DP
drives
