Siemens SINUMERIK Series Function Manual

Z2: NC/PLC interface signals
18.2 Distributed systems (B3)
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
857
18.2.4 Signals from axis/spindle (DB31, ...)
DB31, ...
DBX60.1 NCU link axis active
Edge evaluation: Signal(s) updated:
Signal state 1 or edge
change 0 → 1
Axis is active as NCU link axis.
Signal state 0 or edge
change 1 → 0
Axis is used as a local axis.
Signal irrelevant for ... System with an NCU.
Additional references NCU 7x0.3 PN Manual
DB31, ...
DBX61.2 Axis ready
Edge evaluation: Signal(s) updated:
Meaning The signal is routed on the NCU in the NCU link group to which the axis is physically
connected.
Signal state 1 or edge
change 0 → 1
Axis is ready.
Signal state 0 or edge
change 1 → 0
Axis is not ready.
This status will be set when the channel, the operating modes group or the NCK have
generated the alarm "not ready".
DB31, ...
DBX62.7 Axis container rotation active
Edge evaluation: Signal(s) updated:
Signal state 1 or edge
change 0 → 1
An axis container rotation is active for the axis.
Signal state 0 or edge
change 1 → 0
An axis container rotation is not active for the axis.

Siemens SINUMERIK Series Specifications

General

Axes Control	Up to 31 axes
Category	Control Unit
Manufacturer	Siemens
Series	SINUMERIK
Control Type	CNC
Communication Interfaces	Ethernet, USB
Operating Temperature	0°C to 45°C
Protection Class	IP20
Power Supply	24V DC
Display	Color TFT LCD
