Siemens SINUMERIK Series Function Manual

H1: Manual and handwheel travel
3.12 Data lists
Extended Functions
Function Manual, 03/2013, 6FC5397-1BP40-3BA1
221
Signal name SINUMERIK 840D sl SINUMERIK 828D
Handwheel active DB21, ... .DBX332.0-2 -
Traversing request minus/plus DB21, ... .DBX332.4-5 -
Traversing command minus/plus DB21, ... .DBX332.6-7 -
Orientation axis 1
Handwheel direction of rotation
inversion active DB21, ... .DBX335.0 -
Handwheel active DB21, ... .DBX336.0-2 -
Traversing request minus/plus DB21, ... .DBX336.4-5 -
Traversing command minus/plus DB21, ... .DBX336.6-7 -
Orientation axis 2
Handwheel direction of rotation
inversion active DB21, ... .DBX339.0 -
Handwheel active DB21, ... .DBX340.0-2 -
Traversing request minus/plus DB21, ... .DBX340.4-5 -
Traversing command minus/plus DB21, ... .DBX340.6-7 -
Orientation axis 3
Handwheel direction of rotation
inversion active DB21, ... .DBX343.0 -
JOG retract active DB21, ... .DBX377.4 DB3300, DBX4005.4
Retraction data available DB21, ... .DBX377.5 DB3300, DBX4005.5
3.12.3.6 Signals to axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Feedrate override DB31, ... .DBB0 DB380x.DBB0
Override active DB31, ... .DBX1.7 DB380x.DBX1.7
Delete distance-to-go/spindle reset DB31, ... .DBX2.2 DB380x.DBX2.2
Activate handwheel DB31, ... .DBX4.0-2 DB380x.DBX4.0-2
Traversing key lock DB31, ... .DBX4.4 DB380x.DBX4.4
Rapid traverse override DB31, ... .DBX4.5 DB380x.DBX4.5
Traversing keys minus/plus DB31, ... .DBX4.6-7 DB380x.DBX4.6-7
Machine function 1 INC ... Var. INC DB31, ... .DBX5.0-5 DB380x.DBX5.0-5
Invert handwheel direction of rotation DB31, ... .DBX7.0 DB380x.DBX7.0
JOG fixed point approach DB31, ... .DBX13.0-2 DB380x.DBX1001.0-2
3.12.3.7 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Position reached with coarse/fine exact stop DB31, ... .DBX60.6-7 DB390x.DBX0.6-7
Handwheel override active DB31, ... .DBX62.1 DB390x.DBX2.1
Handwheel active DB31, ... .DBX64.0-2 DB390x.DBX4.0-2
Traversing request minus/plus DB31, ... .DBX64.4-5 DB390x.DBX4.4-5
